5.5KW Rubber Vulcanizing Hot Press For Your Production Needs

Name: 55KW Rubber Vulcanizing Hot Press For Your Production Needs
Brand: Geekung
Price: 10 USD

Best 5.5KW Rubber Vulcanizing Hot Press For Your Production Needs wholesale

Place of Origin : Jiangsu, China

Model Number : JC-XLB150T

Condition : New

Brand Name : Geekung

Voltage : 220V/380V

Dimension(L*W*H) : 1810x1350x1700mm

Weight : 3000kg

Warranty : 1 Year

After-sales Service Provided : Engineers available to service machinery overseas

Color : Blue

Power : 5.5KW

Certification : ISO/CE

Packaging Details : wooden case package/or plastic film package.

Port : Shanghai

Supply Ability : 20 Set/Sets per Month

Price : $10,000.00 - $99,999.00/sets

Payment Terms : T/T

Contact Now

Product Description

Rubber Hot Press Machine/Rubber Vulcanizing Hot Press/ Hot Press Machine:

Workflow:

Initial state→Put rubber in mold→Manually push mold in→Start program→Fast mold closing→Slow lock,pressing→Exhaust→Curing→Mold open→Manually move mold out→Take out finished product.

Specification

Model	JC-XLB63T	JC-XLB100T	JC-XLB150T	JC-XLB200T	JC-XLB250T	JC-XLB300T	JC-XLB350T	JC-XLB500T
Clamping force	63T	100T	150T	200T	250T	300T	350T	500T
Max.sytem pressure	21Mpa	21Mpa	21Mpa	21Mpa	21Mpa	21Mpa	21Mpa	21Mpa
Clamping stroke(mm)	250	250	300	300	300	300	300	300
Rapid clamping speed (mm/s)	≥60	≥60	≥60	≥60	≥60	≥50	≥50	≥50
Platen size(mm)	380x380 400x400	400x400 450x450 500x500	500x500	510x540 600x550	650x550	600x600 700x700	700x700	800x800 1000x850
Max.daylight opening(mm)	350	350	350	350	350	350	350	350
Working layers	Single/Multi	Single/Multi	Single/Multi	Single/Multi	Single layer	Single layer	Single layer	Single layer
Max.temperature(℃)	250	250	250	250	250	250	250	250
Motor power(KW)	3	4	5.5	7.5	7.5	7.5	11	13
Heating power(KW)	9.6	9.6	12	18.6	18.6	20.6	20.6	27.8
Dimension(LxWxH:mm)	1670x1250x1600	1750x1350x1700	1810x1350x1700	1920x1500x2100	1950x1500x2100	2150x1700x2300	2300x1900x2500	2700x2300x3100
Oil tank capacity (Liters)	200	250	280	320	330	350	380	400

Finished Products

5.5KW Rubber Vulcanizing Hot Press For Your Production Needs

5.5KW Rubber Vulcanizing Hot Press For Your Production Needs Images
