air energy Rubber deflashing machine

Name: air energy Rubber deflashing machine
Brand: Mixer
Price: 5 USD

Best air energy Rubber deflashing machine wholesale

Place of Origin : China

Brand Name : Mixer

Type : Rubber Cutting Machine, Vertical type and horizontal type

Condition : New

Video outgoing-inspection : Provided

Machinery Test Report : Provided

Warranty of core components : 5 years

Core Components : PLC, Engine, Bearing, Gear

Voltage : 220V,380V, 415V

Dimension(L*W*H) : 1300x640x1000 mm

Warranty : 1 Year

Key Selling Points : Sustainable

Power (kW) : 4 kW

Weight (KG) : 380 KG

Applicable Industries : Manufacturing Plant

Showroom Location : None

Power(W) : 4KW

Weight : 380kg

After Warranty Service : Video technical support

Certification : CE

Marketing Type : New Product 2020

Packaging Details : wooden case package

Port : Shanghai

Supply Ability : 30sets per months

Price : $5,500.00 - $9,999.00/sets

MOQ : 1set

Delivery Time : 20-30days

Payment Terms : T/T

Contact Now

Product Description

By using the theory of aerodynamic and centrifugal force, this machine is developed to make the rubber flash and rubber products separated,

applicable to all silicone, rubber, nitrile rubber, fluorine rubber seals and other kinds of molded rubber parts, such as O-Ring, rubber plug, gasket,

rubber particles,Y-ring,solid miscellaneous special shaped rubber parts (rubber OD:3-80mm,flash thickness less than 0.2mm,rubber parts with

flash groove),a whole molded rubber product can be processed directly to remove its flash.

Highlights:

1. PLC programming control, touch-screen human-machine digital operation, store all kinds of production process, parameters of each product.

2. Precisely controlled demolition speed, operating performance is simple, intelligent, working sound is low, greatly reduces the operator fatigue.

The machine has feeding position and working station, no need to stop machines every time when feeding, achieving continuous flow operation.

3. Power consumption is only around 3 KW per hour, more importantly, this machine can remarkably reduce labor force, saving workforce cost,

greatly improve production efficiency, the production capacity of one this machine is equivalent at least 50 times of workers’ manual production.

Besides this machine won’t do deformation, damage, dirt to the processed rubber.

4. No need to change any mold or any parts for the machine.

Specification

Motor	4KW (380V,3 Phase,50HZ)
vibrator motor	0.25KW (380V,3 Phase,50HZ)
Compressed air pressure	0.4-0.8 Mpa
Vibrator mesh size	5mm-50mm (customized);standard supply 5 PCS meshes with machine
Working principle	High speed centrifugal tangent technology
Capacity	Equivalent to 30~100 persons’ manual work
Weight	380 kg
Dimension	1300x640x1000 mm
