Rubber cryogenic shotblasting deflashing machine Competitive Price

Name: Rubber cryogenic shotblasting deflashing machine Competitive Price
Brand: Mixer
Price: 25 USD

Best Rubber cryogenic shotblasting deflashing machine Competitive Price wholesale

Place of Origin : Jiangsu, China

Brand Name : Mixer

Type : Rubber Cutting Machine, PLC

Condition : New

Video outgoing-inspection : Provided

Machinery Test Report : Provided

Warranty of core components : 5 years

Core Components : PLC, Engine, Motor, Gear

Voltage : 220V

Dimension(L*W*H) : 984X1000X1935mm

Warranty : 1 Year

Key Selling Points : High-accuracy

Power (kW) : 5.5 kW

Weight (KG) : 1200 KG

Applicable Industries : Manufacturing Plant

Showroom Location : None

Power(W) : 5.5KW

Weight : 1200kg

After-sales Service Provided : Online support

After Warranty Service : Video technical support

Certification : CE ISO

Marketing Type : New Product 2020

Packaging Details : wooden case with film

Port : Shanghai

Supply Ability : 50 Set/Sets per Month

Price : $25,000.00/sets >=1 sets

Contact Now

Product Description

Automatic jet freezer trimmer is a principle of using liquid nitrogen freezing rubber, plastic, aluminum-magnesium alloy products fly side embrittlement occurs rapidly, in this state, a high-speed jet flying plastic projectile hit products for trimming, thereby both high efficiency and high quality products to remove burrs while maintain a trimming device product itself does not change the nature of the characteristics.

Suitable for freezing trimming materials: various plastics, zinc magnesium aluminum die-casting and other products.

30-80 Alternative trimming workers, high efficiency, daily trimming 200-400kg, the product structure is not required, there are holes, the internal structure of complex products can deburring, trimming good effect, good uniformity, You can save the cost of rubber, tooling costs, trimming costs less than artificial;

Specification



Machine size(mm)		984W×1000L×1935H(mm)

power supply			AC380V 50/60HZ 3P

Total power		5.5KW(Projectile wheel motor 3.7KW)

Casting wheel speed			3000-7200rpm

Design temperature			MAX -130℃

Vibrating screen diameter			D500(mm)

Parts basket capacity			60L

Operation interface			Touch scree

Casting wheel size			250(mm)

Refrigerant type and conditions	Liquid nitrogen,and the liquid nitrgen tank you can buy from your country
Media flow systems	Low temperature pressure vessel storage and transportation, pipeline with safety valve, shut-off valve, and equipment connection pipe for special low temperature insulation metal hose
Parts basket dimension	diameter:50CM and depth:40CM
Open/close type	Door type
Basket perforation size	5MM
Usable volume of basket	60L
Throwing wheel diameter	250mm
Speed	7200rpm/M
Media type	Plastic particles
Touch screen size	6 Inch
PLC control	Taida
